The reticle 60 is lighter and finer than the reticle 40, which was widely used only a few years ago. The bars have only half the subtension of the earlier model and there is twice the amount of free space between them. It is therefore ideally suited for precise shooting with the least possible coverage of the target game. With 12x magnification and a subtension of only 0.55 cm at a distance of 100 m, you always have an excellent overview – no fine details are hidden from view. The illuminated dot is extremely bright and can therefore also be used for daytime hunting. The brightness of the illuminated dot can be dimmed at extremely finely, making it ideal for night hunting as well. The reticle is located in the riflescope’s second image plane. The reticle is only suitable for daylight use with modern riflescope models. This may not be possible with older riflescopes for technical reasons. If you have any questions, please contact our customer support.

This reticle was primarily developed for hunting in open terrain and over long distances. The tree-shaped crosshairs are intuitively designed and offer an extremely precise aiming point. The tick marks and dots have a distance of one minute of angle (1 MOA) at the respective reference magnification and always provide a suitable holdover point, even in windy conditions. The ZEISS Hunting app can be used to quickly and precisely determine both bullet drop and wind drift for practically any ammunition, and also displays the distance values in a visual depiction of the reticle. Only the center area of the reticle is illuminated, for precise aiming even in poor lighting conditions. The ZEISS Hunting app can be used to quickly and precisely determine the change in subtension and the resulting bullet drop compensation and wind drift correction values for practically any ammunition.

The ZMOAi-T30 reticle is the illuminated version of the ZMOA-T30. It offers the perfect balance between sport and hunting shooting. Hunters and target shooters prefer this option for their all-around riflescope. The MOA (minute of angle) crosshairs contain MOA tick marks and dots that provide a distance of 1 MOA at reference magnification and cover a bullet drop of 30 MOA. The lateral lines and holdover points are extremely useful for wind correction and are positioned in the field of view for maximum effectiveness and minimum distraction. The reticle illumination is limited to the central fine crosshairs, preventing the shooter from being affected by glare and providing an extremely effective and precise aiming point in adverse lighting conditions. The ZEISS Hunting app can be used to quickly and precisely determine the change in subtension and the resulting bullet drop compensation and wind drift correction values for practically any ammunition.

The very fine reticle 20 is located in the second image plane. During daytime hunting, it enables you to shoulder your rifle and aim extremely precisely, even at long distances. The transition from the bars to the fine lines in the center is arrow-shaped in the reticle 20. This gives you the ability to aim especially precisely at small targets.

The ZEISS ZBR ballistic reticle is located in the second image plane and has a subtension of 2 MOA (ZBR-2) between the tick marks at the respective riflescope’s reference magnification. The tick marks extend in the shape of a Christmas tree over the lower half of the field of view. As such, they are suitable for quickly and simultaneously compensating for bullet drop and correcting wind drift. The ZEISS Hunting app can be used to quickly and precisely determine both values for practically any ammunition, and also displays the distance values in a visual depiction of the reticle.

The ZEISS ZMOA ballistic reticle is located in the second image plane and has a subtension of 2 MOA (ZMOA-2) between the tick marks at the respective riflescope’s reference magnification. Since the tick marks are only shown along the crosshairs, the shooter maintains an excellent overview of the entire field of view. They are suitable for both rapid bullet drop compensation and wind drift correction. The ZEISS Hunting app can be used to quickly and precisely determine both values for practically any ammunition, and also displays the distance values in a visual depiction of the reticle.

The ZMOA-T30 offers the perfect balance between sport and hunting shooting. Hunters and target shooters prefer this option for their all-around riflescope. The MOA (minute of angle) crosshairs contain MOA tick marks and dots that provide a distance of 1 MOA at reference magnification and cover a bullet drop of 30 MOA. The lateral lines and holdover points are extremely useful for wind correction and are positioned in the field of view for maximum effectiveness and minimum distraction. The ZEISS Hunting app can be used to quickly and precisely determine the change in subtension and the resulting bullet drop compensation and wind drift correction values for practically any ammunition.

This reticle was primarily developed for hunting in open terrain and over long distances. The tree-shaped crosshairs are intuitively designed and offer an extremely precise aiming point. The tick marks and dots have a distance of one minute of angle (1 MOA) at the respective reference magnification and always provide a suitable holdover point, even in windy conditions. The ZEISS Hunting app can be used to quickly and precisely determine both bullet drop and wind drift for practically any ammunition, and also displays the distance values in a visual depiction of the reticle. Only the center area of the reticle is illuminated, for precise aiming even in poor lighting conditions. The ZEISS Hunting app can be used to quickly and precisely determine the change in subtension and the resulting bullet drop compensation and wind drift correction values for practically any ammunition.

The ZMOAi-T30 reticle is the illuminated version of the ZMOA-T30. It offers the perfect balance between sport and hunting shooting. Hunters and target shooters prefer this option for their all-around riflescope. The MOA (minute of angle) crosshairs contain MOA tick marks and dots that provide a distance of 1 MOA at reference magnification and cover a bullet drop of 30 MOA. The lateral lines and holdover points are extremely useful for wind correction and are positioned in the field of view for maximum effectiveness and minimum distraction. The reticle illumination is limited to the central fine crosshairs, preventing the shooter from being affected by glare and providing an extremely effective and precise aiming point in adverse lighting conditions. The ZEISS Hunting app can be used to quickly and precisely determine the change in subtension and the resulting bullet drop compensation and wind drift correction values for practically any ammunition.

The ZEISS ZMOA ballistic reticle is located in the second image plane and has a subtension of 1 MOA (ZMOA-1) between the tick marks at the respective riflescope’s reference magnification. Since the tick marks are only shown along the crosshairs, the shooter maintains an excellent overview of the entire field of view. They are suitable for both rapid bullet drop compensation and wind drift correction. The ZEISS Hunting app can be used to quickly and precisely determine both values for practically any ammunition, and also displays the distance values in a visual depiction of the reticle.

The reticle 60 is lighter and finer than the reticle 40, which was widely used only a few years ago. The bars have only half the subtension of the earlier model and there is twice the amount of free space between them. It is therefore ideally suited for precise shooting with the least possible coverage of the target game. With 12x magnification and a subtension of only 0.55 cm at a distance of 100 m, you always have an excellent overview – no fine details are hidden from view. The illuminated dot is extremely bright and can therefore also be used for daytime hunting. The brightness of the illuminated dot can be dimmed at extremely finely, making it ideal for night hunting as well. The reticle is located in the riflescope’s second image plane. The reticle is only suitable for daylight use with modern riflescope models. This may not be possible with older riflescopes for technical reasons. If you have any questions, please contact our customer support.

This reticle was primarily developed for hunting in open terrain and over long distances. The tree-shaped crosshairs are intuitively designed and offer an extremely precise aiming point. The tick marks and dots have a distance of one minute of angle (1 MOA) at the respective reference magnification and always provide a suitable holdover point, even in windy conditions. The ZEISS Hunting app can be used to quickly and precisely determine both bullet drop and wind drift for practically any ammunition, and also displays the distance values in a visual depiction of the reticle. Only the center area of the reticle is illuminated, for precise aiming even in poor lighting conditions. The ZEISS Hunting app can be used to quickly and precisely determine the change in subtension and the resulting bullet drop compensation and wind drift correction values for practically any ammunition.

This reticle is based on the ZMOAi-T20. However, it offers a thicker reticle line of 0.12 MOA at 24x. This makes it easier to see the crosshairs against a dark background, which is especially helpful when you are hunting against a tree line or aiming at dark game in the undergrowth. Only the center area of the reticle is illuminated – an extremely effective and precise aiming point in adverse lighting conditions. The ZEISS Hunting app can be used to quickly and precisely determine the change in subtension and the resulting bullet drop compensation and wind drift correction values for practically any ammunition.

The ZMOAi-T20 reticle is ideal for hunting in open terrain or over long distances. The extremely fine minute of angle (MOA) reticle, with a subtension of only 0.06 MOA at 24x, contains MOA tick marks and dots that provide a distance of 1 MOA at reference magnification and cover a bullet drop of 20 MOA. The lateral lines and holdover points are extremely useful for wind correction and are positioned in the field of view for maximum effectiveness and minimum distraction. Only the center area of the reticle is illuminated – an extremely effective and precise aiming point in adverse lighting conditions. The ZEISS Hunting app can be used to quickly and precisely determine the change in subtension and the resulting bullet drop compensation and wind drift correction values for practically any ammunition.

The ZEISS ZMOA ballistic reticle is located in the second image plane and has a subtension of 1 MOA (ZMOA-1) between the tick marks at the respective riflescope’s reference magnification. Since the tick marks are only shown along the crosshairs, the shooter maintains an excellent overview of the entire field of view. They are suitable for both rapid bullet drop compensation and wind drift correction. The ZEISS Hunting app can be used to quickly and precisely determine both values for practically any ammunition, and also displays the distance values in a visual depiction of the reticle.

The ZEISS ZBR ballistic reticle is located in the second image plane and has a subtension of 1 MOA (ZBR-1) between the tick marks at the respective riflescope’s reference magnification. The tick marks extend in the shape of a Christmas tree over the lower half of the field of view. As such, they are suitable for quickly and simultaneously compensating for bullet drop and correcting wind drift. The ZEISS Hunting app can be used to quickly and precisely determine both values for practically any ammunition, and also displays the distance values in a visual depiction of the reticle.

The ZEISS ZMOA ballistic reticle is located in the second image plane and has a subtension of 1 MOA (ZMOA-1) between the tick marks at the respective riflescope’s reference magnification. Since the tick marks are only shown along the crosshairs, the shooter maintains an excellent overview of the entire field of view. They are suitable for both rapid bullet drop compensation and wind drift correction. The ZEISS Hunting app can be used to quickly and precisely determine both values for practically any ammunition, and also displays the distance values in a visual depiction of the reticle.
